OPC UA

Install asyncua library

The NOVA Python SDK is built upon asyncua, so the structure and methods will be familiar and easier to adapt to. asyncua is a big Python library for OPC UA and thus offers a lot of functionality. Its structure also matches the recommended way of writing Python programs with NOVA.

The NOVA Python SDK offers a convenience wrapper around asyncua to connect to an OPC UA server, reading and writing data, invoking methods, and subscribing to node changes.

Connect to OPC UA server

Create a connection to your OPC UA server using the OPCUAClient context manager.

1. Ensure the OPC UA server is running and accessible via network connection from the NOVA instance.
2. Provide the server URL, e.g., opc.tcp://192.168.0.100:4840.
   The context manager establishes a connection and automatically handles cleanup.

from nova.extentions.opcua.client import OPCUAClient

async def connect_example():
    url = "opc.tcp://192.168.0.100:4840"  # Replace with your server URL

    async with OPCUAClient(url) as client:
        print("Connected to OPC UA server")

Read values from nodes

Read data from specific OPC UA nodes using their node identifiers.

1. Provide the node ID as a string to the read_node method in the correct server format.
   Node identifier follow the OPC UA specification format, e.g., ns=2;s=Machine.Temperature.

   The method returns the current value of the specified node.

from nova.extentions.opcua.client import OPCUAClient

async def read_example(url: str):
    async with OPCUAClient(url) as client:
        temperature = await client.read_node("ns=2;s=Machine.Temperature") # Replace with OPC UA server node ID
        print("Current temperature:", temperature)

Write values to nodes

Send data to OPC UA nodes to control devices or update server values.

1. Provide the target node ID and the value to write.
   Ensure the value type matches what the server expects, Use appropriate data types, e.g., bool, int, float, string.

from nova.extentions.opcua.client import OPCUAClient

async def write_example(url: str):
    async with OPCUAClient(url) as client:
        await client.write_node("ns=2;s=Machine.StartButton", True) # Replace with OPC UA server node ID
        print("Machine start signal sent")

Call server methods

Execute functions or methods defined on the OPC UA server.

1. Provide the parent node ID and the method node ID.
2. Pass any required parameters as additional arguments.
   The method returns the result from the server function.

from nova.extentions.opcua.client import OPCUAClient

async def call_method_example(url: str):
    parent_node = "ns=2;s=Machine.Controller" # Node containing the method, replace with OPC UA server node ID
    method_node = "ns=2;s=Machine.Controller.Reset" # Method to call, replace with OPC UA server method node ID

    async with OPCUAClient(url) as client:
        result = await client.call_node(parent_node, method_node, "param1", 42)
        print("Method result:", result)

Subscribe to node changes

Monitor nodes for value changes and react when specific conditions are met.

1. Define a condition function that returns True when the subscription should stop.
2. Use SubscriptionConfig to customize subscription behavior, e.g., printing received messages.

The subscription stops once the condition is met.

from nova.extentions.opcua.client import OPCUAClient, SubscriptionConfig

def condition(value):
    return value == 100  # Stop when value reaches 100

async def subscribe_example(url: str):
    config = SubscriptionConfig(print_received_messages=True)

    async with OPCUAClient(url) as client:
        await client.watch_node_until_condition(
            key="ns=2;s=Machine.Counter", # Replace with OPC UA server node ID
            condition=condition,
            config=config,
        )
        print("Condition met, subscription stopped")

Read value

Read a device value with opcua_read(host, node_id, config) function.

• host is the address of the OPC UA server, e.g. opc.tcp://0.0.0.0:4840.

• node_id represents the string notation of the OPC UA node id, e.g. ns=2;s=my_node. Read more about the OPC UA node id here .

• config is an optional parameter you can provide to configure the OPC UA client. It must be passed as the last argument. Currently supported config parameters are:

  • request_timeout_seconds: The time in seconds to wait for the response from the server.

host = "opc.tcp://0.0.0.0:4840"
node_id = "ns=2;s=my_node"
config = {
	request_timeout_seconds: 10
}
result = opcua_read(host, node_id, config)
print(result) // prints the value

Write value

Write a value to the OPC UA node with opcua_write(host, node_id, value, config).

• host is the address of the OPC UA server, e.g. opc.tcp://0.0.0.0:4840.
• node_id represents the string notation of the OPC UA node id, e.g. ns=2;s=my_node. Read more about the OPC UA node id here .
• value is any primitive data type supported by Wandelscript.
• config is an optional parameter you can provide to configure the OPC UA client. It must be passed as the last argument. Currently supported config parameters are:
  • request_timeout_seconds: The time in seconds to wait for the response from the server.

host = "opc.tcp://0.0.0.0:4840"
node_id = "ns=2;s=my_node"
config = {
	request_timeout_seconds: 10
}
opcua_write(host, node_id, True, config)

Call method

Call a function defined on the OPC UA server using opcua_call(host, object_id, function_id, argument1, argument2, ..., config). Pass any number of arguments. It returns the function’s return value from the OPC UA server.

• host is the address of the OPC UA server, e.g. opc.tcp://0.0.0.0:4840.
• object_id represents the string notation of the OPC UA node_id where the function is defined, e.g. ns=2;s=my_node.
• function_id represents the string notation of the OPC UA node_id, e.g. ns=2;s=my_node.
• Arguments can be parameters (0, 1, or more) of primitive data types to pass to the OPC UA function. The values are sent in the order they are defined.
• config is an optional parameter you can provide to configure the OPC UA client. It must be passed as the last argument. Currently supported config parameters are:
  • request_timeout_seconds: The time in seconds to wait for the response from the server.

host = "opc.tcp://0.0.0.0:4840"
object_id = "ns=2;s=my_object"
function_id = "ns=2;s=my_function"
config = {
	request_timeout_seconds: 10
}
opcua_call(host, object_id, function_id, True, config)

Get the value returned by the OPC UA function with result. The value returned will be assigned to result.

host = "opc.tcp://0.0.0.0:4840"
object_id = "ns=2;s=my_object"
function_id = "ns=2;s=my_function"
config = {
	request_timeout_seconds: 10
}
result = opcua_call(host, object_id, function_id, True, config)
print(result)

Wait for OPC UA signal

Wait until a node has the desired value using wait_for_opcua_value(host, node_id, value, config). The function will check for equality between the provided value and the node value until both values match. Equality checks are executed whenever the OPC UA server sends a data change notification.

This is the default behavior:

• host is the address of the OPC UA server, e.g. opc.tcp://0.0.0.0:4840.
• node_id represents the string notation of the OPC UA node id, e.g. ns=2;s=my_node. Read more about the OPC UA node id here .
• value is any primitive data type supported by Wandelscript.

This script will wait until the node specified by node_id has the value True:

host = "opc.tcp://0.0.0.0:4840"
node_id = "ns=2;s=my_node"
result = wait_for_opcua_value(host, node_id, True)
print(result) // prints the value

Obtain a certificate

There are two ways you can obtain a certificate:

• CA-signed certificate: You can obtain a certificate from a Certificate Authority (CA). Contact the CA of your choice to get certified.
• Self-signed certificate: You can create a self-signed certificate using the openssl command in your terminal.

  openssl req -x509 -newkey rsa:4096 -keyout key.pem -out cert.pem -days 365 -nodes

  A self-signed certificate will be generated at the location of the command execution. The generated files key.pem and cert.pem will be used in the next steps.

Upload certificate

Wandelbots NOVA provides a storage service where you can store data. You will upload the key.pem and cert.pem files to a folder in the storage service and later use them in Wandelscript.

Upload the cert.pem file

curl --request PUT \
--url http://$(YOUR_NOVA_INSTANCE)/api/v1/cells/$(CELL_NAME)/store/objects/certs/cert.pem \
--form "AnyValue=@cert.pem"

Upload the key.pem file

curl --request PUT \
--url http://$(YOUR_NOVA_INSTANCE)/api/v1/cells/$(CELL_NAME)/store/objects/certs/key.pem \
--form "AnyValue=@key.pem"

The folder name in the storage service is specified via the URL path, in this case certs. If you want a different folder name or structure, adjust the URL path accordingly and make sure to include the file extension .pem.

Pass certificate

Wandelscript functions will use the certificate to establish a secure connection with the OPC UA server.

Use the config parameter security_config to provide the certificate in any of the Wandelscript OPC UA communication functions mentioned above.

host = "opc.tcp://0.0.0.0:4840"
node_id = "ns=2;s=my_node"
config = {
    request_timeout_seconds: 10,
    security_config: {
        security_policy: "Basic256Sha256",
        message_security_mode: "SignAndEncrypt",
        client_certificate_path: "certs/cert.pem",
        client_private_key_path: "certs/key.pem"
    }
}
opcua_write(host, node_id, True, config)

The security configuration allows for four parameters:

1. security_policy specifies the algorithms to use during secure communication.
   Supported algorithms are:
   • Basic128Rsa15
   • Basic256
   • Basic256Sha256
2. message_security_mode indicates the level of security applied to the messages
   • Sign
   • SignAndEncrypt
3. client_certificate_path indicates the path to the client certificate file.
4. client_private_key_path indicates the path to the client private key file.
